Automatic high-precision weighing instruments
Automatic high-precision weighing instruments
Couldn't load pickup availability
description
High-frequency direct vibration, high-precision load cell, high precision weighing, dual display for panel and mainframe weighing;
Continuous weighing (no need to wait. Automatic clearing of 0), fast discharging speed, accurate discharging, intelligent sensing discharging to prevent misoperation and avoid loss;
Storage memories: the formula data is stored and memorized, no need to input next time when the machine is turned on for direct operation;
Visualization panel display, 10-inch touch screen operation, can be equipped with remote communication 485 signals, can realize on-line control;
With historical data storage, according to the needs of the file can be exported to the computer with a U disk to analyze for checking. The instrument comes with weighing repeated nuclear display, to ensure accurate weighing of equipment.
Can be customized according to the needs of different specifications size, weighing range.
Specification
| Product Model | YF-G6081 | YF-G6808 |
|---|---|---|
| Weighing Range | 10-1.5kg (single head) | 10-500g (5 heads) |
| Weighing Accuracy | ±0.1g | ±0.1g |
| Repetition Accuracy | ±0.1g | ±0.1g |
| Working Method | Continuous | Continuous |
| Display Mode | 10-inch touch screen | 7-inch touch screen |
| Container stock | 20KG（single head） | 10KG(5 head） |
| Online Control | optional | optional |
| Communication Interface | RS485 interface / ModBus protocol | RS485 interface / ModBus protocol |
| Customizability | Customized units with multiple heads, other weights on request | Customized units with multiple heads, other weights on request |
